Specifications
-
Standard/Optional Equipment
- Catalog
Maximum Rating
750 ekW
Minimum Rating
500 ekW
Emissions/Fuel Strategy
U.S. EPA Certified
Voltage
208 to 600 Volts
Frequency
60 Hz
Speed
1800 rpm
Duty Cycle
Standby, Prime
Engine Model
Cat® C18 ATAACTM In-line 6, 4-cycle diesel
Bore
5.71in
Stroke
7.2in
Displacement
1106.3in³
Compression Ratio
14:01
Aspiration
Turbocharged Air to Air Aftercooled
Fuel System
Electronic unit injection
Governor Type
Electronic ADEM™ A4
Length - Maximum
138in
Width - Maximum
67in
Height - Maximum
88in
Air Inlet System
Dual element air cleaner
Heavy duty canister air filters
Control System
Annunciators box
Volt free contact
Remote E-Stop button
Discrete I/O module
Earth (Ground) fault relay
Local annunciator
GCCP 1.5
Circuit breakers
Auxiliary contacts
Neutral bar (208V)
Single LSI motorised circuit breaker
Single LSI motorised circuit breaker
External paralleling
Enclosures
Sound attenuated (SA)
Weather protective
Aluminum enclosure
Cooling System
Stone guards
Coolant heater
Jacket water heater with pump
Base / Fuel Tank
Audio & visual fuel alarm
Sub Base Dual Wall Fuel Tank: 660, 1000, 1900, 2200 gal
Fuel System
Sub tank bases: 24 hr & 48 hr
Integral 8 hour tank base
Generator and Attachments
LC frame oversize generators
Space heater control
PMG, AREP
Oversize
Coastal protection (CIP)
Starting and Charging
Battery disconnect switch
5 Amp Battery charger
Oversize battery set
Standard battery set
Certifications
Certification of Compliance � IBC
CSA 22.2
Dual IBC & OSHPD
UL2200 Listed
Seismic
General
Tool set
Lube System
Manual sump pump
Air Inlet System
Aftercooler core
Turbocharger
Control System
3 Pole
GCCP 1.2
Right mounted power centre
Standard breaker
Cooling System
Jacket water pump, gear driven, centrifugal
Thermostats and housing
Coolant level sight gauge
Coolant level sensor
Coolant drain valve; terminated on edge of base
Cooling system filled with Caterpillar extended life coolant
Radiator and cooling fan with belt guards
Exhaust System
Exhaust manifold - dry
Fuel System
Primary fuel filter w/integral water separator and secondary filter
Flexible fuel lines
Fuel cooler
Engine fuel transfer pump
Fuel priming pump
Generator and Attachments
Brushless, self-excited 2/3 pitch, random wound
Insulation Class H and temperature rise
Power centre, IP22 bottom cable entry
Segregated low voltage wiring panel
IP23 Protection
Mounting System
Anti-vibration mounts (Non-captive)
Generator mounting and duct pPlate
Narrow skid base
Protection System
Overspeed
Low oil pressure shutdown
High coolant temperature shutdown
Low coolant level shutdown
Starting/Charging
24 Volt electric starting motor
ALL
Air Inlet System
Aftercooler core
Turbocharger
Control System
3 Pole
GCCP 1.2
Right mounted power centre
Standard breaker
Cooling System
Jacket water pump, gear driven, centrifugal
Thermostats and housing
Coolant level sight gauge
Coolant level sensor
Coolant drain valve; terminated on edge of base
Cooling system filled with Caterpillar extended life coolant
Radiator and cooling fan with belt guards
Exhaust System
Exhaust manifold - dry
Fuel System
Primary fuel filter w/integral water separator and secondary filter
Flexible fuel lines
Fuel cooler
Engine fuel transfer pump
Fuel priming pump
Generator and Attachments
Brushless, self-excited 2/3 pitch, random wound
Insulation Class H and temperature rise
Power centre, IP22 bottom cable entry
Segregated low voltage wiring panel
IP23 Protection
Mounting System
Anti-vibration mounts (Non-captive)
Generator mounting and duct pPlate
Narrow skid base
Protection System
Overspeed
Low oil pressure shutdown
High coolant temperature shutdown
Low coolant level shutdown
Starting/Charging
24 Volt electric starting motor
Optional Equipment
Air Inlet System
Dual element air cleaner
Heavy duty canister air filters
Control System
Annunciators box
Volt free contact
Remote E-Stop button
Discrete I/O module
Earth (Ground) fault relay
Local annunciator
GCCP 1.5
Circuit breakers
Auxiliary contacts
Neutral bar (208V)
Single LSI motorised circuit breaker
Single LSI motorised circuit breaker
External paralleling
Enclosures
Sound attenuated (SA)
Weather protective
Aluminum enclosure
Cooling System
Stone guards
Coolant heater
Jacket water heater with pump
Base / Fuel Tank
Audio & visual fuel alarm
Sub Base Dual Wall Fuel Tank: 660, 1000, 1900, 2200 gal
Fuel System
Sub tank bases: 24 hr & 48 hr
Integral 8 hour tank base
Generator and Attachments
LC frame oversize generators
Space heater control
PMG, AREP
Oversize
Coastal protection (CIP)
Starting and Charging
Battery disconnect switch
5 Amp Battery charger
Oversize battery set
Standard battery set
Certifications
Certification of Compliance � IBC
CSA 22.2
Dual IBC & OSHPD
UL2200 Listed
Seismic
General
Tool set
Lube System
Manual sump pump
